GE 369-HI-R-M-0-D-0-E Motor Management Relay – Enhance Motor Performance & Protection

Number of Digital/Switch Inputs:6 optically isolated

Ambient Humidity:Maximum up to 95% non-condensing

Control Power:nominal: 20 VA; maximum: 65 VA

Dimensions:approx: 11.5 in H x 5.5 in W x 8.5 in L

Fuse:3.15 A H 250 V

Maximum Altitude:2000 m (max)

Phase Current Inputs:1 A and 5 A secondary

Recordable Events:last 512 events

Communications:RS232 port, RS485 port

Ground Current Input Frequency:20 to 100 Hz

Waveform Capture Length:3 buffers containing 16 cycles of all current and voltage channels

Weight:approx. 10 lbs

    The GE 369-HI-R-M-0-D-0-E Motor Management Relay is meticulously designed to monitor and manage industrial motors efficiently. With its advanced waveform capture technology, users can gain critical insights into motor performance and predict potential failures before they occur. The built-in event reporting and data logging functionalities further enhance the reliability and maintainability of your motor systems. The relay supports up to six digital or switch inputs, providing flexibility for various application scenarios. Designed to operate under harsh conditions, it is capable of handling ambient humidity up to 95% non-condensing and can function reliably at altitudes up to 2000 meters. This unit includes an optional metering package, which adds valuable metering capabilities, making it a comprehensive solution for motor management. The compact dimensions and lightweight design make installation straightforward and convenient, ideal for space-constrained environments. By integrating waveform capture, event reports, and data logging, the 369-HI-R-M-0-D-0-E significantly reduces maintenance costs and downtime, ensuring optimal motor operation and longevity.
