GE SR745-W2-P1-G1-HI-E-H – Advanced Transformer Management and Protection System

Model Number:SR745-W2-P1-G1-HI-E-H

Order Number:DS215TCEAG1BZZ01A

Transformer Protection System:Yes

Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz

Display Type:40-character Enhanced LCD

Dimensions:9″H x 7 ⅛”D x 7″W

RTD Type:3-wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum

Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA

Maximum Continuous Voltage Output:273 V

    The GE SR745-W2-P1-G1-HI-E-H is an advanced transformer management system designed for optimal performance in industrial settings.

     With its enhanced 40-character display, it provides a clear and concise interface for easy navigation and manual entry of setpoints.

     The expanded keypad simplifies operation, making it user-friendly even under demanding conditions.

     The robust design allows for seamless installation on a standard 19-inch panel, ensuring compatibility with existing infrastructure.

     Real-time alerts provided by the front-panel LEDs keep operators informed about system statuses and errors, facilitating prompt response to any issues.

     Crafted with high-quality materials, this system ensures durability and reliability, making it an ideal choice for managing transformers, autotransformers, and reactors in critical applications.
