OMRON CP1H-XA40DT1-D Chassis Mount: Precision Control at its Core

Number of Ports:24 Input, 16 Output

Power Supply Voltage:24VDC

Counter Speed:High-Speed Counters

Interrupt Inputs:8 Built-in Interrupt Inputs

Processing Speed:Approximately 500 Instructions per Second

Serial Communication Ports:Two Ports, Selectable RS-232C or RS-485 Option Boards

Safety Standards:CSA, UL (cULus), CE, RCM, and KC Registration

Operating Voltage Range:20.4 to 28.8 VDC

Leakage Current:0.1 mA Max

Common I/O Configuration:PNP Internal I/O Common

    The OMRON CP1H-XA40DT1-D Chassis Mount is designed for seamless integration into existing industrial control systems, offering a robust platform for complex automation tasks. Its advanced pulse output capability ensures smooth operation across four axes, making it an ideal choice for applications requiring high-precision movement control.

    Featuring high-speed counters and differential phases for four axes, this controller simplifies multi-axis control, reducing complexity and increasing efficiency. With eight interrupt inputs built-in, it processes instructions at a rapid pace, significantly speeding up the entire system operation.

    Built with a focus on reliability and safety, the CP1H-XA40DT1-D is compliant with various international standards, ensuring its compatibility and performance across different industries and environments. The aluminum chassis provides durability while maintaining a lightweight design, making it suitable for installation in various industrial settings.

    For enhanced flexibility, users can select option boards for either RS-232C or RS-485 serial communication interfaces, catering to diverse networking requirements. This feature enables seamless data exchange between the controller and external devices, facilitating easier integration into existing systems.

    The compact chassis mount design allows for efficient space utilization in industrial setups, making it particularly attractive for environments where floor space is limited. Whether it’s in manufacturing lines, assembly processes, or quality control systems, the OMRON CP1H-XA40DT1-D Chassis Mount is poised to deliver exceptional performance, enhancing productivity and accuracy in automation tasks.
