Tektronix 5A22N Arbitrary Function Generator

Frequency Range:9 kHz to 30 MHz

Output Amplitude:1 µV to 10 Vpp

Waveform Types:Sine, Square, Pulse, Ramp, Triangle, Noise

Frequency Resolution:1 µHz

Amplitude Accuracy:+/- 2% of setting

Harmonics Distortion:<0.02% at 1 kHz, 1 Vrms

Output Impedance:50 Ω

    The Tektronix 5A22N is designed for precise and flexible signal generation, making it an indispensable tool for engineers and researchers. Its high-frequency range and wide output amplitude ensure that a variety of signals can be accurately produced.

    With a 14-bit resolution, the device ensures minimal distortion and maximum fidelity in the generated waveforms. This is particularly important in applications where signal integrity is critical.

    The instrument supports a wide array of waveform types, including sine, square, triangle, ramp, noise, and arbitrary waveforms. This versatility allows users to simulate a broad spectrum of conditions for thorough testing and analysis.

    The memory depth of 16 kSamples enables complex waveform generation and long-duration signal simulations, which are crucial for detailed testing scenarios.

    Equipped with two output channels, the Tektronix 5A22N can handle multi-channel applications efficiently, enhancing its utility in various industrial settings.
