Tektronix 5B12N Arbitrary Function Generator, High-Precision Signal Generation Module

Frequency Range:0.1 Hz to 20 MHz

Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Arbitrary

Output Amplitude:±20 Vp-p into 50Ω load

Resolution:14-bit vertical resolution

Sampling Rate:200 MSa/s

Bandwidth:DC to 20 MHz

Phase Shift:±90°

Output Impedance:50Ω

    The Tektronix 5B12N Arbitrary Function Generator is designed to meet the demanding requirements of modern industrial control systems. With its broad frequency range from 1 µHz to 50 MHz, it can generate a variety of waveforms including sine, square, triangle, ramp, pulse, noise, and arbitrary signals. The generator’s amplitude resolution of 1 µVpp to 10 Vpp ensures precise control over signal strength, making it suitable for a wide range of applications.

    One of the standout features of the 5B12N is its spectral purity, which typically achieves -90 dBc at a 1 kHz offset. This ensures minimal harmonic distortion, leading to highly accurate signal generation. Additionally, the phase shift capability of ±10° at 50 MHz provides flexibility in creating complex waveforms.

    The generator supports memory depths up to 16 kpts, allowing for extensive waveform storage and recall. Its user-friendly front-panel controls make operation straightforward, while connectivity options such as USB and LAN enable easy integration with other systems and data transfer.

    Designed with durability and reliability in mind, the 5B12N features robust construction and reliable performance. Whether you are testing electronic circuits, calibrating sensors, or performing research and development, the Tektronix 5B12N Arbitrary Function Generator is an indispensable tool for achieving precision and accuracy.
