General Electric 169PLUS-120N-125VDC High-Configurable Motor Protection System

Manufacturer:General Electric Multilin (GE)

Model Number:169PLUS-120N-125VDC

Relay Contacts Maximum Operating Current:10 Amps

Relay Contacts Minimum Permissible Load:5 VDC, 100 mA

Communications:RS422 port

Control Power Frequency:50/60 Hz

Differential Relay Response Time:100 msec

Maximum Operating Temperature Range:-10°C to +60°C

Phase Reversal Relay Response Time:within 3.5 sec. of motor start attempt

Running Hours Counter Accuracy:±1% of primary CT amps

Overload Curves Detection Level:±1% of primary CT amps

Phase Current Input Range:0.05 to 12 × phase CT primary amps setpoint

    The GE 169PLUS-120N-125VDC is an advanced motor protection system ideal for enhancing the reliability and efficiency of industrial motors.

     This model offers superior configurability, enabling it to meet a broad spectrum of operational requirements.

     Key features include precise overload curves detection, robust relay contacts capable of handling up to 10 amps, and a high accuracy running hours counter.

     Its communication capabilities through RS422 port facilitate seamless integration with existing systems.

     Designed for durability, this unit operates effectively within a wide temperature range, from -10°C to +60°C, ensuring reliable performance under varying environmental conditions.

     With its versatile configuration options and user-friendly interface, the 169PLUS-120N-125VDC stands out as a premier choice for industrial motor management and protection.
