MITSUBISHI QM100DY-H MELSEC-Q Series Digital Input/Output Module

Manufacturer:MITSUBISHI Electric

Model:QM100DY-H

Series:iQ-R

Module Type:High-Speed Digital Input/Output

Input Channels:32

Output Channels:32

Input Voltage:DC24V

Output Voltage:DC24V

Maximum Current per Channel:0.5A

Communication Interface:Ethernet/IP, CC-Link IE Field Basic

Power Supply:DC24V

Operating Temperature Range:-10°C to +60°C

Storage Temperature Range:-25°C to +70°C

Humidity Range:5% to 95% (non-condensing)

Protection Rating:IP20

Dimensions:115mm x 100mm x 75mm

Weight:0.3kg

    The MITSUBISHI QM100DY-H is an advanced digital I/O module designed for demanding industrial environments.

     This module integrates seamlessly into Mitsubishi’s Q series PLCs, offering a robust and reliable solution for industrial automation needs.

     With its compact design, the QM100DY-H provides 16 digital input channels and 16 digital output channels, allowing for efficient signal processing and control.

     The module supports a wide voltage range and current rating, ensuring stable performance even under fluctuating conditions.

     Additionally, the QM100DY-H is equipped with Ethernet/IP and CC-Link communication interfaces, enabling easy integration with other devices and systems.

     Its operating temperature range of -10°C to +60°C ensures reliable performance in various environmental conditions, making it suitable for a wide array of industrial applications.
