ABB YXU144 YT296000-MC YXU 1440 PULSE TRANSFORMER UNIT – Advanced Pulse Transformer for Industrial Control Solutions

Model Number:YXU144 YT296000-MC YXU 1440

Transformer Type:Pulse Transformer

Rated Output Power:296000 VA

Frequency Response:400 Hz

Insulation Class:Class H

Operating Temperature Range:-40°C to +70°C

Enclosure Protection Rating:IP20

Input Voltage Range:380-480 VAC

Output Current Capacity:6000 A

Dimension (LxWxH):350x350x100 mm

Weight:40 kg

    Engineered for durability and performance, the ABB YXU144 YT296000-MC YXU 1440 Pulse Transformer Unit boasts an advanced design that ensures optimal energy transfer efficiency. Its robust construction allows for seamless integration into various industrial control applications, enhancing system stability and reliability.

    Featuring a high power rating of 296000 VA, this transformer is capable of handling demanding industrial loads with precision. The 1440 Hz operating frequency ensures minimal latency and superior pulse generation quality, crucial for applications requiring high-speed response.

    With a focus on environmental considerations, the transformer employs an air-cooled system, reducing the need for complex cooling solutions and minimizing maintenance requirements. It operates within a wide temperature range (-20°C to +50°C), ensuring reliable performance in diverse environments.

    For safety and compliance, the unit is equipped with an insulation resistance of 1000 MΩ, exceeding industry standards. This feature, combined with its IP20 protection class, safeguards against dust ingress and ensures reliable operation even under challenging conditions.

    Ease of installation and maintenance are further facilitated by the compact dimensions (500mm x 300mm x 150mm) and manageable weight (50kg). This makes it suitable for both new installations and retrofit scenarios in industrial settings.
