Pepperl+Fuchs UC500-30GM-IUR2-V15 Ultrasonic Sensor, Industry-grade Precision Measurement

Sensing Range:30mm to 500mm

Transducer Frequency:80kHz

Operating Voltage:DC 12V to 36V

Current Consumption:Max 10mA

Response Time:≤ 2ms

Environmental Temperature Range:-25°C to +85°C

Protection Class:IP67/IP68

Material:Stainless Steel

Mounting Options:Panel, Mounting Bracket, or Mounting Hole

Output Signal:Analog Current or Voltage

Communication Interface:Parameterization via Service Program ULTRA 3000

Adjustable Parameters:Acoustic Power, Sensitivity

    Engineered with precision, the P+F UC500-30GM-IUR2-V15 ultrasonic sensor provides unparalleled accuracy and durability for demanding industrial environments. This sensor is designed to measure distances accurately within its wide sensing range of 30 to 500 millimeters, making it suitable for various applications including conveyor belt monitoring, part detection, and safety systems.

    Equipped with a 40 kHz transducer, this ultrasonic sensor ensures high-frequency measurements for reliable distance readings under various conditions. It supports a versatile operating voltage range of 12 to 36 volts DC, ensuring compatibility with a wide variety of industrial power supplies. With a maximum current consumption of 35 milliamps, the sensor efficiently utilizes energy for optimal performance.

    Designed for robust operation in challenging environments, the P+F UC500-30GM-IUR2-V15 features an IP67 protection class, making it resistant to dust, water splashes, and harsh conditions commonly encountered in manufacturing plants. Its panel mount style facilitates easy installation and integration into existing systems.

    Offering versatile output types, the sensor can provide either 4-20mA analog current or 0-10V analog voltage signals, which are widely used in control systems for seamless data transmission. Additionally, it supports MODBUS RTU communication protocol, enabling seamless integration with PLCs and other automation equipment.

    The P+F UC500-30GM-IUR2-V15 ultrasonic sensor is engineered to withstand extreme temperature ranges from -25°C to +70°C, ensuring continuous and accurate operation throughout the year. Its compact design and durable construction make it an ideal choice for applications requiring high reliability and precision.
