Operating Environment:Humidity up to 90% non-condensing
Weight:Approximately 5kg
Voltage Input:60 to 120V
Relay Dimensions:9”H, 7 ⅛”D, 7”W
Number of Logic Inputs:16
Fuse Type:.5 × 20 mm slow-blow Littelfuse
Analog Input Type:DC mA
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
Windings Per Phase:3
Resistant Temperature Device (RTD) Type:3 wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40 character Enhanced LCD
The GE 745-W3-P5-G5-HI-A-L-R-E-H is an advanced transformer management relay that seamlessly integrates with industrial control systems. Its compact design ensures efficient space utilization on the control panel without compromising functionality.
This relay boasts a versatile display type, featuring a 40 character Enhanced LCD screen that provides clear, readable information under various lighting conditions. The display facilitates easy monitoring of transformer parameters, enhancing operational efficiency.
With its robust overload withstand capability, the GE 745-W3-P5-G5-HI-A-L-R-E-H can handle up to 1 second at 80 times rated current, and maintain continuous operation at 3 times rated current. This feature ensures the relay remains functional even under severe operational stress.
The use of a .5 × 20 mm slow-blow Littelfuse fuse type ensures that the relay can safely interrupt the circuit in the event of a fault, minimizing damage to the transformer and preventing potential hazards. The DC mA analog input type allows for precise measurement of current, providing critical data for effective control and monitoring.
Designed with user-friendliness in mind, the GE 745-W3-P5-G5-HI-A-L-R-E-H comes equipped with a detailed manual and online support resources. These resources guide users through setup, configuration, and troubleshooting, ensuring smooth integration and optimal performance in real-world applications.
